Piston Pump Automatic Paint Dispenser Tint Machine 250ML Flow Rate

Certification
China FOSHAN EGO TINTING CO.,LTD certification
China FOSHAN EGO TINTING CO.,LTD certification
I'm Online Chat Now

Piston Pump Automatic Paint Dispenser Tint Machine 250ML Flow Rate

Piston Pump Automatic Paint Dispenser Tint Machine 250ML Flow Rate
Piston Pump Automatic Paint Dispenser Tint Machine 250ML Flow Rate

Large Image :  Piston Pump Automatic Paint Dispenser Tint Machine 250ML Flow Rate

Product Details:
Place of Origin: CHINA
Brand Name: YIJIU
Certification: CE
Model Number: YJ-1A-16D
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Packaging Details: PLYWOOD CASE
Delivery Time: 30 days
Payment Terms: TT
Supply Ability: 50 SETS PER MONTH
Detailed Product Description
Application:: Water Based And Oil Based Colorant Dispensing Flow: Sequential
Maximal Dispensing At One Time:: 50 ML Circuit Flow Rate: 250ML
Minimum Dispensing: 1/384 Y Or 0.077 ML Allowed Each Dispensing Difference: +/- 0.02ML Each Time Of Dispensing
Can Table Size: 30 X 35 CM Pump Type: Piston Pump
Machine Size: 720(L)*810(W)*1315(H) MM
High Light:

Piston Pump Automatic Paint Dispenser

,

250ML Automatic Paint Dispenser

,

Piston Pump Paint Tint Machine

Automatic paint dispenser , colorant dispenser machine for paint shop or paint factory




Automatic paint dispenser smart design



  • Compact and highly reliable, the YJ-1A-16D offers users the assurance of quality and engineering expertise.The dispenser machine can be personalized with your business logo and identity, providing a valuable new element in your branding and promotion strategy.
  • High Cost-Effective makes it popular all over the world. The reliability and experience obtained on this unit make it truly an ideal working partner, enhancing the tinting business and contributing to the business’s bottom line.






Technical Data

Pump type Piston pump
Dispensing flow Sequential
Canister inner diameter sizes 90mm
Canister configurations Up to 16
Circuit flow rate [l/min] 0,25L
Canister material Stainless Steel
Minimum dispensed quantity [fl.oz.] 0.077ml / 1/384Y
Power supply 110V/ 220V ±10%
Frequency 50/60 HZ
Rated power 150W



DISPENSER DIMENSIONS

  1. Length : 805MM
  2. Width : 710MM
  3. Height :1245MM
  4. Machine Weight : 182KG



PACKING DIMENSIONS

  1. Length : 840MM
  2. Width : 750MM
  3. Height :1400MM
  4. Gross Weight : 216KG



Brief introduction



YJ-1A-16D automatic paint dispenser has been designed to meet high standards for accuracy, repeatability and speed, at an attractive price level that makes this dispenser a truly convenient working tool for many store environments.

  • It is not only precisely controls the dispensing of ingredients to provide excellent finished paint product repeatability from batch to batch, but also can serve as a complete inventory management system.
  • Since it dispenses by piston pump, any desired batch size is precisely dispensed as needed.
  • The system handles everything from formula storage.With software modules included for raw material (colorants) and finished product inventory. It is the simple to operate and easy to maintain.





Driver 50 is a user Software Package developed for our range of Automatic Paint Dispenesr machines. The package will assist the user in carrying out the following operations:

  • Dispensing: Read the data from formula software and start dispensing;
  • Manual Dispensing: The dispensing under this function can be done without formula software. The user can choose any colorants from the dropdown list, decide the amount for each colorant, and dispense here.
  • Colorant management: manage all the datas of colorant.
  • Debug: test each function of the machine manually;
  • Pump calibration: calibrate the pulse data of each canister pump;
  • Presentation management: translate the display language into your local language.



Features




  • The undispensed nozzle will dispense a little colorant in a specified time to keep the colorant from drying,which can effectively prevent the nozzle from blocking.
  • Automatic stirring at set time, prevent the colorant inside canisters from subsidence.Piston pump ensure you precise measurement,free of calibration life-long.
  • Ceramic valve structure, with good corrosion resistance and good sealing,stable and reliable.
  • The rolling brush will clean seal ring of nozzle automatically.
  •
  • The refilling height of just 1245 mm make it one of the lowest units in the market. The open upper canister area is equally a true advantage for the operator.
  • Driver software use the same Flink.dat file as CPS/Hero/Lenteq,and Formula.txt file as TECMEC,it’s compatible with worldwide major color software.



Our Service


  • Training:You can send personnel to our factory for free training on the machine.
  • Testing of equipments: all our machines are tested before shipment. All machines are at its optimal state when shipped.
  • Inspection: You can send inspectors to our factory for inspection or we self-inspect following the technical requirements mentioned in contracts.


Warranty


Limited Warranty: We provide a one year warranty for automatic paint dispenser. Within guarantee period, we can help you judge the fault according to the failure phenomenon via Internet way and send replacement part to you. If the fault has been caused by mis-used or abnormal conditions of operation, repairs will be billed at a normal cost in this case. An estimate will be submitted before repair work is started in case requested.
