Semi Automatic Clamping Manual Paint Mixing Machine 110V/220V CE with Shaker
Detailed Product Description
|Time Of Mixing::
||Acceptable Can Weight And Volume::
||1-35KG , 1 - 20L
|Acceptable Can Size::
||Diameter: Within 320mm , Height: 80-380mm
||Speed Of Mixing::
||Clockwise And Anticlockwise Rotating
||Net Weight / Gross Weight:
||180 KG / 240 KG
||110V / 220V ± 10%
CE Manual Paint Mixing Machine,
110V Manual Paint Mixing Machine,
220V automatic clamping paint shaker
YIJIU YJ-2M-01 Manual clamp color mixing mechanism ,
Semi - auotmaitc gyroscopic paint mixer machine
|Time of Mixing
|Size of Mixing can
|Load of Mixing can
|Speed of Mixing
||80r/min~ 150 r/min
|Height of Mixing can
|Net Weight / Gross Weight
||180KG / 240KG
||810 (L) X 830 (W) X1150 (H) MM
||740 (L) X 800 (W) X1070 (H) MM
- Mixing time setting: 15 second to 9 min 45 second (If special requirement , please tell us which time you want when place the order).Cooling time can be customized. (Please check with us when you place order)
- Manual clamping and loosening the mixing can, easy to operate and maintain.The lower clamping plate can be pulled out, easy for loading the big and heavy paint drum on it.
- Rotation and revolution go simultaneously, 2 directions rotation,counterclockwise rotate then Clockwise rotate,mix more evenly. Stable, even and fast stirring.
- Electrode tube indicator,more convenient and clear
- The YIJIU manual clamping gyroscopic mixer YJ-2M-01 is works on the theory that the table revolve around the shaft meanwhile rotate on their axes with the character of high-efficiency , high-speed . It is suitble to big package and high viscosity chemical liquids mixing .
- Application: Chemical liquids : paint colorant , coating , ink , glue , etc.
Mixer machine FAQ
1. Which type of drums can be used for mixer ?
Round or Square both OK, but the upper and bottom should be flat.
2. Can it adjust time and speed?
Time: 0-5 mins
Speed: two levels, low speed for big cans and high speed for small cans.
3. How to judge big can or small can?
Big can: Height more than 26cm ( fastest speed: 100 rpm / min)
Small can: Height less than 26cm ( fastest speed: 150 rpm / min)
4. What's the max mixing ability?
20L, 35 kg, 5 US gallon
5. Can it be used for other liquid except paint?
Yes, any liquid chemicals
