Semi Automatic Clamping Manual Paint Mixing Machine 110V/220V CE with Shaker

Certification
China FOSHAN EGO TINTING CO.,LTD certification
China FOSHAN EGO TINTING CO.,LTD certification
I'm Online Chat Now

Semi Automatic Clamping Manual Paint Mixing Machine 110V/220V CE with Shaker

Semi Automatic Clamping Manual Paint Mixing Machine 110V/220V CE with Shaker
Semi Automatic Clamping Manual Paint Mixing Machine 110V/220V CE with Shaker

Large Image :  Semi Automatic Clamping Manual Paint Mixing Machine 110V/220V CE with Shaker

Product Details:
Place of Origin: CHINA
Brand Name: YIJIU
Certification: CE
Model Number: YJ-2M-02
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Packaging Details: PLYWOOD CASE
Payment Terms: L/C, T/T
Supply Ability: 50 SETS PER MONTH
Detailed Product Description
Time Of Mixing:: 15s-9min45s Acceptable Can Weight And Volume:: 1-35KG , 1 - 20L
Acceptable Can Size:: Diameter: Within 320mm , Height: 80-380mm Speed Of Mixing:: Adjustable(80r/min--150r/min)
Mixing Way: Clockwise And Anticlockwise Rotating Net Weight / Gross Weight: 180 KG / 240 KG
Voltage: 110V / 220V ± 10%
High Light:

CE Manual Paint Mixing Machine

,

110V Manual Paint Mixing Machine

,

220V automatic clamping paint shaker





YIJIU YJ-2M-01 Manual clamp color mixing mechanism ,

Semi - auotmaitc gyroscopic paint mixer machine






Technical Data


Time of Mixing 15s-9min45s
Size of Mixing can 1~20 L
Load of Mixing can 1~35 KG
Speed of Mixing 80r/min~ 150 r/min
Height of Mixing can 80~380 mm
Power Supply 110/220V±10%, 50HZ
Rated Power 750W
Net Weight / Gross Weight 180KG / 240KG
Packing Size 810 (L) X 830 (W) X1150 (H) MM
Machine Size 740 (L) X 800 (W) X1070 (H) MM



Semi Automatic Clamping Manual Paint Mixing Machine 110V/220V CE with Shaker 0





Feature

  1. Mixing time setting: 15 second to 9 min 45 second (If special requirement , please tell us which time you want when place the order).Cooling time can be customized. (Please check with us when you place order)
  2. Manual clamping and loosening the mixing can, easy to operate and maintain.The lower clamping plate can be pulled out, easy for loading the big and heavy paint drum on it.
  3. Rotation and revolution go simultaneously, 2 directions rotation,counterclockwise rotate then Clockwise rotate,mix more evenly. Stable, even and fast stirring.
  4. Electrode tube indicator,more convenient and clear





Brief Introduction


  • The YIJIU manual clamping gyroscopic mixer YJ-2M-01 is works on the theory that the table revolve around the shaft meanwhile rotate on their axes with the character of high-efficiency , high-speed . It is suitble to big package and high viscosity chemical liquids mixing .
  • Application: Chemical liquids : paint colorant , coating , ink , glue , etc.




Mixer machine FAQ


1. Which type of drums can be used for mixer ?
Round or Square both OK, but the upper and bottom should be flat.



2. Can it adjust time and speed?
Yes!
Time: 0-5 mins
Speed: two levels, low speed for big cans and high speed for small cans.



3. How to judge big can or small can?

Big can: Height more than 26cm ( fastest speed: 100 rpm / min)

Small can: Height less than 26cm ( fastest speed: 150 rpm / min)



4. What's the max mixing ability?
20L, 35 kg, 5 US gallon

5. Can it be used for other liquid except paint?
Yes, any liquid chemicals
